MobiHack

Step 1 — network discovery Found the camera on the LAN at an internal address with an nmap -sn sweep after confirming the laptop and camera were on the same subnet (earlier attempts failed because the laptop was on a different network with client isolation — common on guest/shared Wi-Fi, and it hides every device from every other device).

Step 2 — full port scan A full TCP scan (nmap -p- --min-rate 2000) against the camera's IP turned up a cluster of open ports that look like a Chinese ODM "cloud cam" P2P stack rather than a standard ONVIF/RTSP IP camera:

4000/tcp  open  (HTTP, embedded web server, 400 on malformed request)
7000/tcp  open  (no banner on connect)
7678/tcp  open  (no banner on connect)
8001/tcp  open  (no banner on connect)
8002/tcp  open  (no banner on connect)
8080/tcp  open  (HTTP — "Server: WebServer", CORS * — 403 on /, 404 on every
                 known camera CGI path we tried: hi3510, ISAPI, CGIProxy,
                 onvif/device_service, snapshot.cgi, videostream.cgi, etc.)
8187/tcp  open  (no banner on connect)
9110/tcp  open  (no banner on connect)
15500/tcp open  (no banner on connect)
35597/tcp open  (no banner on connect)

No RTSP (554/8554), no ONVIF, no Telnet (23 — connection refused), no plain HTTP admin page. The ports that answer HTTP return generic embedded-webserver errors with no identifying paths we've found yet. The silent, binary-only ports (8001/8002/15500/etc.) are consistent with a proprietary P2P/"Kalay"-style SDK that only responds to its own handshake, not plain HTTP or a line-based protocol — which is most likely why plain curl/nc probes get nothing back.

Step 3 — manufacturer / FCC research Mobi Technologies, Inc.'s FCC grantee code (Y4N) is confirmed via fccid.io, but every filing under it we could find so far (70294R, 70290T, 70236, 70209T, DW700TX/RX) is for Mobi's older analog/900MHz wireless monitor line, not the Wi-Fi HDX. The HDX's Wi-Fi radio module is very likely a separate, pre-certified module from a different OEM/grantee — commonly how budget Wi-Fi cameras get built — whose FCC ID is printed on a label on the camera itself (on the bottom or inside the battery/stand compartment). We don't have a confirmed FCC ID for the HDX yet.

Step 4 — clones / chipset family No confirmed chipset ID yet. The open-port signature doesn't match the most commonly-cloned budget IP-camera families we checked against:

• Xiongmai (XM) / Hi3518-family — usually exposes TCP 34567 (NetSDK) and often Telnet 23 with known default creds (admin/12345, xmhdipc/666666, etc. — well documented from the 2017 Mirai-adjacent disclosures). Not present here — 34567 and 23 are both closed.
• Hi3510-family CGI cams — expose /cgi-bin/hi3510/*.cgi. Not present — all 404.
• ONVIF-compliant cams — expose /onvif/device_service. Not present.

The port cluster (8001/8002/7678/15500/9110/35597 all open with no banners) looks more like a ThroughTek Kalay-adjacent or a smaller Shenzhen ODM's proprietary P2P/cloud stack, which several baby-monitor brands license rather than build themselves. We have not yet matched it to a specific published SDK name — this section will be updated as soon as we do.

Step 5 — default passwords / root technique no result yet — no Telnet, no SSH, no discovered admin HTTP path to even try default credentials against. The embedded web server on 8080 answers requests but 403/404s everything we've thrown at it. The practical paths left, in order of how destructive/irreversible they are:

1. Packet-capture the official MobiCam app talking to the camera on the LAN (no cloud round-trip needed for local discovery/handshake on some of these SDKs) to learn the real wire protocol on 8001/8002/etc., rather than guessing CGI paths blind.
2. Pull the firmware via the app's own OTA/update flow (if it checks a plain HTTP(S) URL for updates, the binary can be grabbed and inspected without touching the device) — far safer than flashing anything.
3. UART/SPI-flash dump by opening the case — last resort, and the one irreversible step if done wrong, so it won't happen without sign-off first.
